Description

Soundcraft 5056046 Vi2000 Digital Mixing System

The Soundcraft 5056046 Vi2000 Digital Mixing System provides live sound engineers, touring productions, and A/V installations with a comprehensive mixing solution featuring three touchscreens, 28 faders, 24 busses, advanced SpiderCore processing, and multiple effect options. A host of powerful features including Faderglow, VM2 microphone monitoring, and Vistonics provide an intuitive and user-friendly mixing experience, while the 40-bit floating-point DSP environment, running STUDER, BSS, Lexicon, and dbx algorithms ensure outstanding sound quality for your events.

Features:

  • For Touring, Venues & A/V Installations
  • 28 Faders, 24 Mono/Stereo Busses
  • 3 Touchscreens, 2 Engineers Work at Once
  • FadeGlow Processing
  • MADI/Dante, Ethernet, USB, MIDI & DVI
  • SpiderCore 40-Bit Floating Point Engine
  • 4 Independent Stereo Multi-Effects
  • Optional Soundcraft Realtime Rack
  • Optional Stagebox Monitor Modules

Specifications:

  • Control Surface:
    • Input Faders: 16
    • Output Faders: 8 +3 (LRC masters) +1 (Monitor A/B)
    • Total Faders: 28
    • 3D Vistonics screens: 3 (2 input, 1 master)
  • Local I/O Physical connectors:
    • Mic/Line Inputs: 48, 32 or 16 configurable (max 3x 16ch out cards of 4 total) (Last 5 outs default to local monitors but can be repatched)
    • AES/EBU In: 2 (=4ch) plus optional 16ch via Vista1 card (remove 2 mic or line out cards to fit).
    • AES/EBU Out: 2 (=4ch) plus optional 16ch via Vista1 card (remove 2 mic or line out cards to fit).
    • TB Mic in: 1 front panel, with rear-switched 48V.
  • DSP Mixing Core:
    • Processing: 40-bit Floating point, 48kHz sample rate
    • Input Channels to mix: 96 mono Pairable to 48 stereo
  • External Control Ports:
    • Ethernet: 1 (dedicated HiQnet / Realtime Rack control)
    • MIDI: 1 In, 1 Out
  • Frequency Response:
    • Stagebox Mic input to Line output: +0/-1dB, 20Hz-20kHz
    • AES/EBU In to AES/EBU Out: +0/-0.2dB, 20Hz-20kHz
  • T.H.D. & Noise: 22Hz-22kHz
  • Mic Input E.I.N.: < -126dBu (150 Ohm source)
  • Residual Noise: -91dBu
  • AES/EBU Input Sample Rate: 32-108kHz (with SRCenabled)
  • Mains Power Consumption: 250W
  • Temperature/Humidity Range:
    • Operating Temperature Range: 0°C to 45°C (32°F to 113°F)
    • Relative Humidity: 0% - 90%, non-condensing Ta=40°C (104°F)
    • Storage Temperature Range: -20°C to 60°C (-4°F to 140°F)
  • Dimensions:
    • Height (Console Only): 13.8" / 351 mm
    • Width (Console Only): 45.5" / 1155 mm
    • Depth (Console Only): 31.6" / 803 mm
    • Height (with Factory Flightcase): 44.1" / 1121 mm
    • Width (with Factory Flightcase): 48.9" / 1243 mm
    • Depth (with Factory Flightcase): 20.4" / 517 mm
