RCF SUB 15-AX Active 15 Inch Powered Subwoofer with 2200 Watt Class-D Amplifier - Black

The SUB 15-AX is a portable 15" high-power active subwoofer for live sound applications with fully featured processing, a color touch panel, and remote control via Bluetooth®. The combination of a latest-generation transducer with a powerful Class-D amplifier delivers sound pressure levels up to 133 dB with exceptional clarity and headroom. SUB AX subwoofers are designed specifically for small to mid-sized venues and ideal for portable applications. SUB 15-AX is the ideal complement for 10" or 12" woofer-size loudspeakers; it centralizes speaker management inside the subwoofer, providing dual crossovers, 8-band EQs, routing, delays, cardioid configurations, and recallable crossover presets. The polyurea-coated all-wood cabinet features a sealed Powercon True1 Top connector.

Features:

• 2200 Watt Class-D Amplifier
• 133 dB MAX SPL
• 15” Woofer, bass reflex housing
• Digital Crossover w/ Presets
• Multi-ply hardwood polyurea-coated
• LiveRemote App
• Dual XLR/TRS combo Input + Link, Dual XLR Xover Out
• Bass Motion Control excursion management
• Powercon True1 Top Sealed AC Connector

Specifications:

• Acoustical Specifications:
  • Frequency Response: 35 Hz ÷ 120 Hz
  • Max SPL @ 1m: 133 dB
• Transducers:
  • Woofer: 15", 3.0" v.c
• Input/Output Section:
  • Input signal: bal/unbal
  • Input connectors: Combo XLR/Jack
  • Output connectors: XLR
  • Input sensitivity: -2 dBu/+4 dBu
• Processor Section:
  • Protections: Thermal
  • Limiter: Soft Limiter
  • Controls: Encoder for Volume control and data entry. Touch Screen for parameter management and monitor.
• Power Section:
  • Total Power: 2200 W Peak, 1100 W RMS
  • Cooling: Convection
  • Connections: Powercon TRUE1 TOP IN/OUT
• Standard Compliance:
  • Safety agency: CE compliant
• Physical Specifications:
  • Handles: 1 handle per side
  • Pole mount/Cap: Yes
  • Color: White
  • Dimensions (HxWxD): 23.23 x 16.54 x 23.23 inches
  • Weight: 26 kg / 57.32 lbs
