RCF S 19 Passive 19 Inch Bass Reflex Subwoofer - 1500 Watt RMS - Black

The S 19 is a high-power single 19" subwoofer suitable for RCF Installed Sound systems. The bass-reflex design ensures an efficient acoustic response down to 30 Hz. The high-quality plywood cabinet is finished with a black, heavy-duty polyurea coating and protected by a powder-coated metal grille. The recessed input panel features two Speakon NL4 connectors, allowing a quick and safe connection. A M20 pole mount adaptor on top of the cabinet and handles on both sides are provided. Both models can be ground-stacked and are cardioid-arrayable for improved rear rejection.

Features:

• Up to 1500 W power handling
• 139 dB max SPL
• 30 ÷ 200 Hz frequency range
• 19" HyperVented Neodymium Woofer with 4’’ v.c.
• High-quality polyurea-coated multi-ply cabinet
• Steel front grille with clothing
• M20 standard pole mount in top end of cabinet
• Speakon NL4 connectors

Specifications:

• Acoustical Specifications:
  • Frequency Response (-10dB): 30 Hz ÷ 200 Hz
  • Max SPL @ 1m: 139 dB
• Power Section:
  • Amplification: Full Range
  • Nominal Impedance: 8 ohm
  • Power Handling: 1500 W
  • Peak Power Handling: 6000 W PEAK
• Transducers:
  • Woofer: 19'' neo, 4.0'' v.c
• Input/Output Section:
  • Input Connectors: Speakon® NL4
  • Output Connectors: Speakon® NL4
• Standard Compliance:
  • Safety Agency: CE compliant
• Physical Specifications:
  • Handles: 2 side
  • Pole Mount/Cap: Yes
• Physical & Dimensions:
  • Height: 534 mm / 21.02 inches
  • Width: 650 mm / 25.59 inches
  • Depth: 730 mm / 28.74 inches
  • Weight: 44 kg / 97 lbs
