RCF NX915-SMA 15-Inch Professional Active Stage Monitor
NX 915-SMA speaker is a stage monitor designed for sound providers, musicians, bands, and DJs. The combination of a 1.75” compression driver, 15” woofer, two-channel 2,100W amplifier, and the TRW waveguide produces coherent 100° x 70° coverage for the listening area with up to 131dB SPL of distortion-free sound. Used as a stage monitor, stand-alone speaker system, or satellite paired with a subwoofer, the NX 915-SMA blends high performance and reliability in a compact package. Combining RCF proprietary FiRPHASE and Bass Motion Control DSP processing, NX 915-SMA Series speakers deliver absolute clarity and deep, powerful bass response. The tour-ready, rugged all-wood cabinet is easy to carry and set up on stage or on a pole.
Features:
- Up to 131 dB Sound Pressure Level
- 2100W Class-D bi-amplification
- 45-20000 Hz linear frequency response
- 1.75" Compression Driver
- 15" Woofer
- FiRPHASE zero degrees phase technology
- Bass Motion Control woofer excursion management
- 70ºx100º Constant Directivity Coverage Angle
- Perfectly tailored for horizontal or vertical deployment
Specifications:
- Acoustical Specifications:
- Frequency Response: 45 Hz ÷ 20000 Hz
- Max SPL @ 1m: 131 dB
- Horizontal coverage angle: 100°
- Vertical coverage angle: 70°
- Transducers:
- Compression Driver: 1 x 1.0", 1.75" v.c
- Woofer: 15", 2.5" v.c
- Input/Output Section:
- Input signal: bal/unbal
- Input connectors: Combo XLR/Jack
- Output connectors: XLR
- Input sensitivity: -2 dBu/+4 dBu
- Processor Section:
- Crossover Frequencies: 1600 Hz
- Protections: Thermal, RMS
- Limiter: Soft Limiter
- Power Section:
- Total Power: 2100 W Peak
- High frequencies: 700 W Peak
- Low frequencies: 1400 W Peak
- Cooling: Convection
- Connections: Powercon TRUE1 TOP IN/OUT
- Standard Compliance:
- Safety agency: CE compliant
- Physical Specifications:
- Cabinet/Case Material: Plywood
- Handles: 1 on side and 1 on top
- Pole mount/Cap: Yes
- Grille: Steel
- Color: Black
- Size:
- Height: 357.3 mm / 14.07 inches
- Width: 705 mm / 27.76 inches
- Depth: 456.6 mm / 17.98 inches
- Weight: 17.3 kg / 38.14 lbs
- Shipping Information:
- Package Height: 745 mm / 29.33 inches
- Package Width: 505 mm / 19.88 inches
- Package Depth: 425 mm / 16.73 inches
- Package Weight: 20 kg / 44.09 lbs
