RCF NX-915A Active 15-Inch 2-Way Powered Speaker
NX 915-A is masterfully engineered from the ground up to deliver stellar audio performance for solo musicians, bands, and DJs. The combination of 1.75" compression driver, 15" woofer, two-channel 2100W amplifier, and a constant directivity waveguide produces coherent 100° x 60° coverage for the listening area with up to 131 dB SPL, distortion-free sound. Used stand-alone speaker for FOH system, satellite (with subwoofer), stage monitor, or flown speaker, the NX 915-A blends high-performance and reliability in a compact package. Blending RCF proprietary FiRPHASE and Bass Motion Control DSP processing, NX 9 Series speakers are perfectly tuned for each model, delivering absolute clarity and deep, powerful bass response. The tour-ready, rugged all-wood cabinet is easy to carry and secure to install on a pole-, flown-, wall-, or truss-mounted using the dedicated rigging points available.
Features:
- Up to 131 dB Sound Pressure Level
- 2100W Class-D Bi-Amplification
- 45-20000 Hz linear frequency response
- 1.75" Compression Driver
- 15" Woofer
- FiRPHASE zero degrees phase technology
- Bass Motion Control woofer excursion management
Specifications:
- Acoustical Specifications:
- Frequency Response: 45 Hz ÷ 20000 Hz
- Max SPL @ 1m: 131 dB
- Horizontal coverage angle: 100°
- Vertical coverage angle: 70°
- Transducers:
- Compression Driver: 1 x 1.0", 1.75" v.c
- Woofer: 15", 2.5" v.c
- Input/Output Section:
- Input signal: bal/unbal
- Input connectors: XLR, Jack
- Output connectors: XLR
- Input sensitivity: -2 dBu/+4 dBu
- Processor Section:
- Crossover Frequencies: 1600 Hz
- Protections: Thermal, RMS
- Limiter: Soft Limiter
- Controls: Linear, Boost, Stage, Volume
- Power Section:
- Total Power: 2100 W Peak
- High frequencies: 700 W Peak
- Low frequencies: 1400 W Peak
- Cooling: Convection
- Connections: VDE
- Standard Compliance:
- Safety agency: CE compliant
- Physical Specifications:
- Cabinet/Case Material: Plywood
- Hardware: 2 x M10 Top, 1 x M10 each side, 1 x M10 bottom, 1 x M10 rear
- Handles: 1 x Each Side
- Pole mount/Cap: Yes
- Grille: Steel
- Color: Black
- Size:
- Height: 705 mm / 27.76 inches
- Width: 420 mm / 16.54 inches
- Depth: 451 mm / 17.76 inches
- Weight: 24.1 kg / 53.13 lbs
- Shipping Information:
- Package Height: 751 mm / 29.57 inches
- Package Width: 506 mm / 19.92 inches
- Package Depth: 474 mm / 18.66 inches
- Package Weight: 26.6 kg / 58.64 lbs
