QSC K Series K12.2 12-Inch 2-Way 2000W Powered Speaker

The QSC K.2 Series is quite simply, the next standard in powered loudspeakers. To start, each model is equipped with a 2000W power module carefully matched to high-performance woofers and compression drivers. DMT (directivity-matched transition) ensures smooth coverage across the entire listening area. Advanced on-board DSP provides Intrinsic Correction voicing and advanced system management to further optimize performance. Superbly flexible, the K.2 Series provides its operators with a library of preset contours for common applications such as Stage Monitor, Dance Music, Musical Instrument Amplification, Hand-held Microphone and more, while also offering storable Scenes to recall user-configurable settings such as input type, delay, EQ, cross-over and selected contour. Operated as either main PA or as a floor monitor, each model can also be flown, wall- or truss-mounted, or placed on a speaker pole, either straight-firing or with 7.5° down-tilt. Rugged, light-weight and incredibly stylish, the K.2 Series also features a global 6-Year Warranty with product registration.

Advanced Power and DSPThe 2000W power module delivers ample burst and continuous power for the loudspeaker’s premium drivers. It has been designed with very low-noise fan cooling, enabling the enclosures to be used in settings where background noise must be kept to a minimum. Carefully tailored, subtle and sophisticated dynamics processing is used to protect the drivers from damage and the performance from distortion.

Flexible DesignEach model is housed in a rugged ABS enclosure with a professional yet unobtrusive appearance that is at home in any application. Each model can be utilized in either main PA or floor monitor applications, while ergonomic handles and a heavy-duty steel grille with fabric lining further enhance overall appearance and functionality. The dual pole cups allow a zero or 7.5 degree downward tilt when deployed on a pole. This allows for more even coverage across the listening area and less problems due to rear wall reflections. For suspended applications, integrated M10 fittings with a single pullback are included to accommodate M10 eyebolts.

Features:

• Best in class audio performance
• 2000W class-D amplifier module
• Factory presets and savable/recallable scenes for commonly-used applications such as stage monitor, dance music, musical instrument amplification, hand-held microphone and more
• Multi-function digital display for control and selection of loudspeaker functions including cross-over, EQ, delay and frequency contours Intrinsic Correction tuning and loudspeaker management
• DMT (directivity-matched transition) design provides excellent power response and consistent performance across the listening area (75-, 90-, 105-degree, K12.2, K10.2, K8.2)
• Refined, professional appearance looks great in any application
• Rugged ABS enclosure for long life and lasting durability
• Deployment in either main PA or floor monitor position
• Dual pole cup mounts (straight-firing and 7.5° down-tilt)
• M10 fittings for flown applications
• Optional security panel prevents unauthorized tampering of controls
• 6-Year Warranty with product registration

Specifications:

• Configuration: multi-purpose, 2-way powered loudspeaker
• LF transducer: 12" (305 mm), cone
• HF transducer: 1.4" (35.6 mm) titanium diaphragm compression driver
• Frequency response (-6 dB): 50 Hz - 20 kHz
• Frequency range (-10 dB): 45 Hz - 20 kHz
• Nominal coverage angle: 75° axisymetric
• Maximum rated SPL1: 130 dB @1 M, peak 126 dB @ 1 M, continuous
• Amplifier: Class D Peak: 1800 W (LF), 225 W (HF)
• Cooling: low-noise, variable speed fan
• Controls: power, 3 x level, rotary encoder (push), 2 x selection buttons
• Indicators: monochrome LCD display 1.75" x 1" (45 mm x 25.4 mm), 2 x power LED (front and rear), 3 x input signal LED, input A mic selected LED, input B Hi-Z selected LED, limiter active LED
• Connectors: 2 x locking XLR/F ¼" combo (mic/line input and Hi-Z/line input), 1 x 3.5 mm TRS (Stereo Input), 2 x XLR/M (loop-thru output), 1 x XLR/M (mix output), 1 x locking IEC power connector
• AC Power Input: universal power supply 100 – 240 VAC, 50 – 60 Hz
• AC Power Consumption: 100 VAC, 2.1 A / 120 VAC, 1.9 A / 240 VAC, 1.1 A
• Enclosure: impact resistant ABS
• Attachment points: 2 x M10 threaded inserts plus pull-back
• Color: black
• Grille: 18 gauge powered coated steel, internal cloth lining
• Dimensions: 23.7" x 14" x 13.8" (HxWxD)
• Net weight: 39 lbs./17.7 kg
• Regulatory: CE, WEEE, UL, China RoHS, RoHS II, FCC Class B
