HK Audio Linear 9 118 Sub A 1100Watt 18Inch Subwoofer
The LINEAR 9 118 Sub A is a true powerhouse. Its bass-reflex construction allows for compact dimensions, and weighing in at just 42 kilograms, it is extremely easy to transport. A powerful punch, precise playback and impressive low frequency performance make this active bass the ideal complement to the mid/high units. What’s more, it meets all the requirements for quickly and easily implementing effective cardioid setups, both mechanically and with the available filter sets. Thanks to its stereo preamplifier, it is also ideal for use in 2.1 systems.
Features:
- 1100W RMS / 2200 Program
- Network Controllable DSP with 4 Presets
- Front, Cardioid 1:1, Cardioid 2:1, Remote
- DSP: 10-Band Parametric EQ, Mute
- HPF, LPF, Polarity, Level, Delay, Limit
- Powerful Punch, Precise Playback
- Impressive Low-Frequency Performance
- Lightweight and Easy to Transport
- Simple Handling and Transport
Specifications:
- Max. SPL @ 10% THD: 129 dB half space (42 Hz – 100 Hz averaged)
- Max. SPL peak @ 10 % THD: 131 dB half space
- Frequency response +/-3 dB: 42 Hz – X-over
- Frequency response -10 dB: 38 Hz – X-over
- Power amp output (RMS): 1100 W
- Amp type: Class D
- LF driver: 1x 18", 4" voice coil
- Maximum input level: +20 dBu
- Analog inputs: 2x XLR combo balanced
- Analog thru: 2x XLR balanced
- DSP Out: 1x XLR balanced
- Network port: Ethercon RJ45, 1x In, 1x Thru
- Filter presets: Front, Cardioid 1:1, Cardioid 2:1, Remote
- Remote software: DSP CONTROL (Windows, macOS)
- DSP functions: Fully parametric 10-band EQ with variable filter characteristics, Low-Pass Filter, Polarity, Level, Delay, Limiter, Mute
- Sample rate: 96 kHz
- System latency: Less than 2.6 ms
- Mains connector: 1x Powercon NAC3 In, 1x Powercon NAC3 Thru, 100–240 V
- Power consuption: 1.9 A / 100–240 V nominal according to EN 62368-1
- Pole mount: 1x M20
- Carrying handles: 2x MultiGrip
- Housing: Birch multiplex
- Finish: PU coating black
- Front grille: 2 mm metal grille backed with black acoustic foam
- Dimensions (WxHxD): 55 x 56 x 69 cm 21-21/32 x 22-3/64 x 27-11/64"
- Weight: 41.5 kg / 91.5 lbs
