HK Audio Linear 5 MKII 112 FA 1200Watt 12Inch Active Multifunctional Loudspeaker

The LINEAR 5 MK II FA models are powerful full-range mid/high units with a transparent, full sound. Due to the longer horns, they achieve impressive throw distances. As a stereo system, the FA models provide the necessary extra low-end and punch. A special filter adapted to the characteristics of the LINEAR 5 MK II subwoofers, which can be selected via a preset, makes it possible to use the LINEAR 5 MK II FA models as system mid/high units with high usable output in various systems in no time at all. The horn dispersion facilitates horizontal and vertical clustering. With optional TB-45N or TB-45NQ tilt brackets attached to the MultiGrips, the FA models can be rigged easily and safely.

Specifications:

• Max. SPL @ 10 % THD: 128 dB half space (70 Hz – 12 kHz averaged)
• Max. SPL Peak @ 10 % THD: 135 dB half space
• Frequency response +/-3 dB: 70 Hz – 12 kHz
• Frequency response -10 dB: 55 Hz – 19 kHz
• Power amp output (RMS/Peak): 600 / 1,200 W
• Amplifier type: Class D – bi-amped
• Low/mid speaker: 1 x 12", 2.5" voice coil
• HF driver: 1", 1.7" voice coil
• Horn characteristics: 60° x 40° CD horn, rotatable
• Active x-over frequency: 1.6 kHz FIR X-over with 72 dB/oct.
• Maximum input level: 20 dBu
• Analogue inputs: 1 x XLR combo balanced
• Analogue Thru: 1 x XLR balanced
• DSP-Out: 1 x XLR balanced
• Network port: EtherCON RJ45, 1 x In
• Filter presets: Flat, Boost, Low Cut, Remote
• Remote software: DSP CONTROL (Windows, Mac OS)
• DSP functions: Fully parametric 10-band EQ with variable filter characteristics, High-Pass Filter, Low-Pass Filter, Polarity, Level, Delay, Limiter, Mute
• Sample rate: 48 kHz
• System latency: Less than 2 ms
• Mains connection: 1x IEC connector with V-Lock securing system, 100-240 V
• Power consumption: 1 A / 100–240 V nominal according to EN 62368-1
• Pole mount: DuoTilt 3°/7°
• Rigging points: 3x M8 (AP-8)
• Carrying handles: 2 x MultiGrip
• Housing: Hybrid (birch multiplex/MDF)
• Surface: Black acrylic enamel
• Front grille: 2 mm metal grille backed with black acoustic foam
• Dimensions (WxHxD): 37 x 67 x 36.5 cm 14-9/16 x 26-3/8 x 14-3/8"
• Weight: 21.9 kg / 48.28 lbs
