GLP FR10 Bar Tourpack 3 with Stackable Case
The GLP FR10 Bar Tourpack 3 includes three FR10 Bar fixtures, six Omega brackets, and six 5070-B clamps, all packed in a robust stacking case for efficient transport and storage. The FR10 Bar delivers exceptional lighting capabilities with advanced LED technology, offering versatile control and effects for professional stage and event lighting. The included Omega brackets and clamps provide secure mounting, ensuring stability and flexibility in various configurations. The stacking case ensures protection during transit, making this tour pack ideal for touring productions and large-scale events.
GLP FR10 Bar
With a new optical system, the impression FR10 Bar uses a larger size output aperture, as used in the impression FR1 giving a new look from a familiar style. The impression FR10 Bar contains 10 sources, each containing a high output 60 Watt RGBW LED that color matches with the entire GLP X4 and FR series of fixtures. Each individual source features smooth, full range color mixing with strong, punchy output from a homogenized Fresnel lens. Along with individual color control, the impression FR10 Bar contains a series of built in color macros and a large reference of industry standard color filters.
Features:
- 10x 60 Watt RGBW Osram® LEDs
- Individual Zoom for each lens separately
- Micro Fresnel lenses for punchy output
- Pencil-Beam Effect
Specifications:
- Light Source:
- Type: RGBW
- Light Source Count: 10
- Light Source Power: 60 W
- Light Source Lifetime: 50,000 hours
- CRI (Ra): 80+
- CQS: 80+
- TLCI: 80+
- TM-30 Rf: 77
- TM-30 Rg: 106
- Optical System:
- Output: 8,000 lm
- Min. Zoom: 3.7°
- Max. Zoom: 34°
- Zoom Ratio: 1:7
- Effects:
- Dimmer / Shutter: 0 – 100% electronic, two dimming curves
- Strobe and Pulse Effects: Regular and random
- Shutter: Electronic
- Color Mixing: RGBW, variable 0 – 100%
- CTC (Color Temperature Control): Variable, 2,500 – 10,000 K
- Color Wheel: Virtual, 15 colors, rotation and random
- Internal Effects: Color presets
- Tilt: 210°
- Zoom: Motorized
- Position Correction System: Position feedback
- Control:
- DMX Channels: 25, 51, 57, 79
- Control Modes: Normal, Pixel-Mapping, 4 modes
- Protocol: DMX (USITT DMX512-A), RDM (ANSI/ESTA E1.20), Art-Net, sACN
- Setting and Addressing: Control panel with backlit graphic display, DMX, RDM
- Display: Illuminated graphic LCD, self-charging buffer battery, automatic orientation of the display
- Cooling: Temperature controlled, overheating protection
- Software Update: DMX link
- Stand-Alone: DMX-Snapshot via DMX
- High-Res Channels: Dimming, Tilt
- Performance Modes: Fast, Medium, Smooth
- Dimming Curves: Linear, Soft
- Fan Modes: Regulated, High, Medium, Low
- Connectors:
- Signal Connection: XLR 5-Pin, etherCON (In/Out)
- Power Input: Neutrik powerCON TRUE1 (In/Out)
- Electrical Specifications:
- Power Input: 100 – 240 VAC / 50 – 60Hz
- Power Supply: Auto-ranging electronic switch-mode
- Power Supply Cable: US: 16 A, 14 AWG, UL listed, E304117, SJT, 4.9 ft / EU: 16 A, 1.5 mm², H05VV-F, 1.5 m
- Fuse: T15A 250 V 6x32mm
- Max. Power (@230V): 740 W
- Typical Power (@ 230V): 710 W
- Minimum Power (@230 V): <60 W
- Power Factor: >0.95 / 230 V AC, >0.98 / 115 V AC
- Thermal Specifications:
- Cooling: Temperature controlled, overheating protection
- Max. Surface Temperature (Ta = 40°C): 80°C / 176°F
- Max. Ambient Temperature (Ta max.): 45°C / 115°F
- Min. Ambient Temperature (Ta min.): 5°C / 40°F
- Total Heat Dissipation (calculated, +/-10%): 2,430 BTU/h
- Mounting Options:
- Mounting: 2 eyelets for safety cable, 4 pairs of 1/4-turn locks
- Safety Wire Attachment: Foldout eyelets
- Standing: Rubber feet
- Hanging (Vertically): Omega-Bracket
- Orientation: Any
- Location: Dry
- Minimum Distance to Combustible Materials: 0.2 m / 8 in
- Minimum Distance to Illuminated Surfaces: 1.0 m / 39.4 in
- Construction:
- Housing Color: Black
- Housing Material: Aluminum, steel metal plates
- Protection Rating: IP 20
- Construction Features: Base handles, Tilt-Lock-System, changeable front screen
- Dimensions & Weight:
- Height (Head Vertical): 339 mm / 13.3 in
- Width (Head): 1,000 mm / 39.4 in
- Width (Across Yoke): 1,000 mm / 39.4 in
- Length: 196 mm / 7.7 in
- Min. Center-to-Center: 170 mm / 6.7 in
- Weight: 24 kg / 53 lbs
