ETC ColorSource Spot V Light Engine with Multiverse / 15-30 Degree Zoom Lens Tube - White
The ColorSource Spot V brings an amazing richness of color and increased brightness to any space, all at an affordable price point. With a five-color array including red, green, blue, indigo, and lime, this light fixture can create both soft pastels and bold, saturated colors all from a single source. Plus, it features wireless DMX/RDM control using Multiverse technology, NFC configuration from your mobile device, and next-level brightness that make it super versatile and easy to use. Please note that lens tubes, adapters, and retrofits are sold separately.
Features:
- Five-color array (red, green, blue, indigo, and lime)
- Simple user interface with seven-segment display
- Powercon True1 top connector
- DMX/RDM in and thru (5-pin XLR)
- Multiverse wireless DMX/RDM
- NFC (near field communication) configuration
- LED droop compensation
- Optically calibrated
- Tour-ready, aluminum housing
- Combine with available adapters to transform your fixture into a fully functional Fresnel or CYC light (adapters sold separately)
Specifications:
- Source
- LED details: 60 Lumileds LUXEON® C and LUXEON Rebel LEDs
- Max lumens: 9,498
- Lumens per watt: 48
- L70 rating (hours to 70% output): 54,000 hours
- Color
- Colors used: Red, green, blue, indigo, lime
- Color temperature range: Color mixing
- Calibrated array: Yes
- Red shift: No
- Optical
- Beam Angle Range: Swappable lens tubes, 15-30 degree included
- Gate size: 80 mm
- Aperture size: 6.25" – 14" (depending on lens tube)
- Pattern projection: Yes
- Pattern size: A or B
- Control
- Input method: DMX512 via 5-pin XLR connector
- Protocols: DMX512/RDM
- Modes (footprint): 4 modes
- RDM configuration: Yes
- UI type: Seven-segment, three-button interface
- Wireless
- Band: 2.400–2.480 GHz
- Range: 100 m indoors, 500 m line of sight (subject to conditions)
- Max receivers:
- DMX: No limit
- RDM: Varies by transmitter used
- Multiverse SHoW Baby: 585
- Multiverse Transmitter: 5,000
- Broadcast power: 100 mW
- Electrical
- Voltage range: 100–240 VAC 50/60 Hz
- Input method: powerCON TRUE1 TOP power in and thru
- Thermal
- Ambient operating temp: 32° – 104° F (0° – 40° C)
- Droop compensation: Yes
- dB range: 24.4 dBA average at 1 m
- Physical
- IP rating: IP20
- Color: White
- Weight: 17 lb (7.7 kg)
- Source
- LED details: 60 Lumileds LUXEON® C and LUXEON Rebel LEDs
- Max lumens: 9,498
- Lumens per watt: 48
- L70 rating (hours to 70% output): 54,000 hours
- Color
- Colors used: Red, green, blue, indigo, lime
- Color temperature range: Color mixing
- Calibrated array: Yes
- Red shift: No
- Optical
- Beam Angle Range: Swappable lens tubes, 15-30 degree included
- Gate size: 80 mm
- Aperture size: 6.25" – 14" (depending on lens tube)
- Pattern projection: Yes
- Pattern size: A or B
- Control
- Input method: DMX512 via 5-pin XLR connector
- Protocols: DMX512/RDM
- Modes (footprint): 4 modes
- RDM configuration: Yes
- UI type: Seven-segment, three-button interface
- Wireless
- Band: 2.400–2.480 GHz
- Range: 100 m indoors, 500 m line of sight (subject to conditions)
- Max receivers:
- DMX: No limit
- RDM: Varies by transmitter used
- Multiverse SHoW Baby: 585
- Multiverse Transmitter: 5,000
- Broadcast power: 100 mW
- Electrical
- Voltage range: 100–240 VAC 50/60 Hz
- Input method: powerCON TRUE1 TOP power in and thru
- Thermal
- Ambient operating temp: 32° – 104° F (0° – 40° C)
- Droop compensation: Yes
- dB range: 24.4 dBA average at 1 m
- Physical
- IP rating: IP20
- Color: White
- Weight: 17 lb (7.7 kg)
