Elation FUZE-WASH-500 500 Watt RGBMA LED Wash Moving Head Fixture
The Elation Professional FUZE WASH 500 is a professional automated LED Fresnel wash fixture designed for theater, television, and various other lighting applications. Its high-CRI engine utilizes a 5-color homogenized LED array consisting of red, green, blue, mint, and amber sources, each carefully tuned for accurate color reproduction. Ideal for applications requiring an automated Fresnel fixture with impactful colors, a wide zoom range, and a soft field, the FUZE WASH 500 also offers an optional indexable ovalizer lens for additional beam control.
Features:
- 500W full spectrum RGBMA LED engine
- Up to 17,000 total lumen output at 6500K
- CRI up to 92
- Wide zoom range from 10° to 45°
- Variable 16-bit dimming curve modes
- CMY emulation
- Virtual color correction
- Green/magenta shift
- Virtual gel swatch book
Specifications:
- Fixture Type: Moving Head
- Light Source: Color LED - 500 W
- Colors: Red, Green, Blue, Mint, Amber
- Control Protocols: DMX512, W-DMX, RDM, Art-Net, sACN
- AC Input Power: 100 to 240 VAC, 50/60 Hz
- Power/Current Consumption: 609 W
- Mounting: Floor Base
- Color Temperature: 2400 to 8500K
- Lumen Output: 17,000 Lumens
- Zoom Adjustment: Motorized, 10 to 45°
- Dimming: 16-Bit
- Control Protocols: DMX512, W-DMX, RDM, Art-Net, sACN
- DMX Channel Modes: 6 Modes: 17 / 20 / 21 / 24 / 26 / 30-Channel
- Inputs/Outputs: 1 x XLR 5-Pin DMX Input, 1 x XLR 5-Pin DMX Output, 1 x RJ45 Network Input, 1 x RJ45 Network Output, 1 x USB-A Service Input
- Power Connector: 1x powerCON TRUE1 Input, 1x powerCON TRUE1 Output
- Environmental Resistance: Dust-Resistant (IP20)
- Operating Temperature: 14°F to 113°F (-10°C to 45°C)
- Dimensions: 21.7 x 16.06 x 10.07" (55.1 x 40.79 x 25.58 cm)
- Weight: 40.8 lb (18.5 kg)
- Fixture Type: Moving Head
- Light Source: Color LED - 500 W
- Colors: Red, Green, Blue, Mint, Amber
- Control Protocols: DMX512, W-DMX, RDM, Art-Net, sACN
- AC Input Power: 100 to 240 VAC, 50/60 Hz
- Power/Current Consumption: 609 W
- Mounting: Floor Base
- Color Temperature: 2400 to 8500K
- Lumen Output: 17,000 Lumens
- Zoom Adjustment: Motorized, 10 to 45°
- Dimming: 16-Bit
- Control Protocols: DMX512, W-DMX, RDM, Art-Net, sACN
- DMX Channel Modes: 6 Modes: 17 / 20 / 21 / 24 / 26 / 30-Channel
- Inputs/Outputs: 1 x XLR 5-Pin DMX Input, 1 x XLR 5-Pin DMX Output, 1 x RJ45 Network Input, 1 x RJ45 Network Output, 1 x USB-A Service Input
- Power Connector: 1x powerCON TRUE1 Input, 1x powerCON TRUE1 Output
- Environmental Resistance: Dust-Resistant (IP20)
- Operating Temperature: 14°F to 113°F (-10°C to 45°C)
- Dimensions: 21.7 x 16.06 x 10.07" (55.1 x 40.79 x 25.58 cm)
- Weight: 40.8 lb (18.5 kg)
