Elation DESIGN-BEAM-1200C 1200W Pro Moving Head

• CMY + 8 colors + 6/7 gobos
• 1200 Watt Hybrid VNSP-Beam / Wash Moving Head
• Hybrid Spot / Wash In One
• 6.7° Very Narrow Beam Angle
• Modular Construction
• EWDMX + RDMX + Fan & Lamp Control
• Variable Frost, Prism

• CMY Color Mixing + Variable CTO
• 8 static / replaceable dichroic colors including CTB and UV

• 6 Rotating / indexing gobos (replaceable)
• 7 Static replaceable gobos

• Rotating / indexing 3-facet prism
• Variable Frost for hard edge BEAM or WASH effect

• Strobe effect (1-18) flashes per second
• Continuous mechanical dimmer 0-100%

• 47,040 Lux / 4,370 FC @ 32.8 feet / 10 meters
• Lamp life: 750hrs 7,500°k, CRI 85
• Lamp: Phillips MSR1200 SA/DE lamp

• Very tight 6.7° beam angle with extreme output, great ACL effect!
• 3 phase motors for fast movement
• Extreme light output - over 850,000 Lux at 2.5 meters

• Pan / Tilt Lock - 630° or 540° Pan (selectable) x 265° Tilt
• Pan/Tilt lock

• 32 DMX channels extended mode,
• 21 DMX channels standard mode
• 19 DMX channels basic mode
• Digital LCD blue / white menu display
• DMX Record function on-board
• EWDMX + RDMX + Fan & Lamp Control
• 16 Bit Movement and Color fading
• 16 bit mode
• 3 User settable personality DMX traits

• DB Rating - 56.3db @ 0.91m
• Compact case design (575 size case)

• Electronic ballast
• Voltage: 208-240v / 50-60hz
• Power consumption: 7.4A 1,536W

• 3 pin or 5 pin DMX in/out

• Dimensions (L x W x H): 18.5" x 18.2" x 20.3" / 470 x 367 x 657.5mm (Head up)
• Weight: 78.5 lbs / 30 kg

• cETLus approved
