Da-Lite 14104FL Tensioned Advantage Series 121x216 Surface / Roller / Motor

The Tensioned Advantage ceiling recessed electric screen series from Da-Lite is designed with a pre-installed ceiling trim, concealing the rough opening and eliminating the need for additional trim work after installation. The two-stage installation process allows the screen case to be installed during rough-in construction and the screen surface assembly during the finishing stage. With sliding installation brackets, mounting is flexible, enabling easy attachment of the screen housing to the structure above the drop ceiling. The SightLine feature gives the screen a floating appearance, using a suspension system with thin cables to eliminate the need for a black drop.

Features:

• Standard Low Voltage Control (LVC) for flexible screen operation
• UL Plenum rated case
• White powder-coated case for a clean aesthetic
• Decora-style, three-button wall switch
• 12" of black drop (2" for Parallax Pure surfaces)
• Smooth Roll Technology for a perfectly flat screen
• TruGuide Electric Screen Tensioning System for optimal viewing surface smoothness
• Standard black backing to retain projected brightness
• Seamless surfaces in all models

Specifications:

• Type: Ceiling Recessed Electric Screen
• Aspect Ratio: HDTV (16:9)
• Size: 121" x 216" (247" diagonal)
• Surface: HD Progressive 0.6
• Black Drop: Standard
• Voltage: 120V (60Hz)
• Control: Standard Low Voltage Control (LVC)
