Clear-Com Eclipse HX-DELTALITE 16P Intercom Frame

The Clear-Com Eclipse HX-DELTALITE 16P Intercom Frame comes with (16) analog ports, slots for two CPU cards, four I/O interface cards and three interface modules. Two external power supplies are provided. RJ45 and fiber connectors are located on the rear of the chassis, connecting the CPU and interface cards to intercom devices and media, such as user keypanels, interfaces, 4-wire audio equipment, wireless equipment and fiber optic cables.

The Clear-Com Eclipse HX-DELTALITE 16P Intercom Frame is designed for smaller setups where up to 16 users need to be connected. This configuration is suitable for modest productions or installations with fewer communication needs.

Features:

• Two Versions- 1 CPU card, 1 MVX card and 1 open slot for any card- 1 CPU card, 2 MVX cards* Each version has 3 interface modules slots
• Software license to unlock all card slots
• Up to 80 internal ports
• Dual PSUs for redundancy
• Dual cooling fans
• Alarms for frame temperature, external PCU failure and fan failure
• Front to rear LAN/Panel patch
• Front carrying handles for easy rack installation and extraction
• Fully compatible with Clear-Com V-Series Iris, V-Series, iStation, ICS panels and Agent-IC® mobile app
• Replaceable fan/alarm card
• Replaceable power card
• Supported by EHX software for configuration and management

Specifications:

• Matrix Capabilities:
• Maximum Expansion Cards: 2
• Maximum CPU Cards: 1 (included)
• Maximum Power Supply Units: 2 (included)
• Maximum Fiber Expansion Cards: 1 (if second slot available)
• Maximum MVX Port Cards: 2
• Minimum MVX Port Cards: 1
• Maximum E-QUE, IVC-32, LMC-64 Port Cards: 1 (if second slot available)
• Maximum E-IPA 16, 32 or 64 Port Card: 1 (if second slot available)
• Maximum EMADI-64 Port Cards: 1 MADI (if second slot available)
• Maximum RJ45 Ports per Matrix: 64
• Maximum Timeslots: 512
• Matrix Performance:
• Sample Rate: 48 kHz
• Resolution: 24 bit
• Frequency Response: at 48 kHz sampling: 30 Hz - 22 kHz ± 3 dBu
• Crosstalk (adjacent channel): <-70 dBu
• Nominal Level: 0 dBu
• Matrix headroom: +18 dBu
• Distortion: <0.05 %, @ 0 dBu, 300 Hz to 10 kHz; <0.1 %, @ 0 dBu, 100 Hz to 20 kHz
• Off Noise: <-70 dBu (20 Hz - 22 kHz)
• On Noise: <-65 dBu (20 Hz - 22 kHz)
• Key Response, Intra-System: <40 ms for audio route
• Linked Systems: <60 ms for audio between matrices
• Power Supplies:
• Quantity: 2 per matrix
• Mounting: External
• AC Power Input: IEC (1 per PSU)
• Power Consumption: 150 Watts Maximum
• Status Indicators: LEDs viewable from front of rack
• Environmental:
• Operating Temperature: 32°F - 104°F (0°C - 40°C)
• Storage Temperature: -67°F - 158°F (-55°C - 70°C)
• Humidity: 90%, non-condensing
• Dimensions:
• 19 x 5.25 x 17.5 in. (WxHxD)
• (482 x 133 x 445 mm)
• Weight:
• Empty: 18 lbs (8.2 kg)
• Fully Loaded: 32.5 lbs (14.7 kg)

*NOTE: Product appearance may differ due to current cards inserted.
