Chauvet WDMX Micro T-1 TRX G5 Wireless Tranceiver

Wireless Solutions Micro T-1 Transceiver works with W-DMX wireless wash lights, including all Well and Maverick fixtures, to generate a wireless control signal for both DMX and RDM protocols. These compact devices can also be set up to transmit or receive W-DMX signals to make any fixture or rig wireless. It also features a 5 V USB power supply or can be used with (4) AAA batteries for up to 4 hours in transceiver mode and 8 hours in receiver mode. Indicator LEDs easily show signal strength, battery life, and transceiver or receiver mode.

Features:

• Transmit and receive 1 universe of W-DMX and RDM protocols
• Power with included 5V USB power supply or (4) AAA batteries (not included)
• Batteries last for up to 8 hours in receiver mode and 4 hours in transceiver mode
• Built in indicator lights for signal and battery strength, as Well as operation modes
• Can be used directly with any Maverick or Well fixtures
• Can be used to make any lighting system wireless for data

Specifications

• Dimensions: 3.94 x 1.57 x 2.65 in (100 x 40 x 65 mm)
• Weight: 1.67 lb (800 g)
• Exterior Color: dark gray
• Housing Material: High-impact flame-retardant polymer

• Power Connection: 5V micro USB connector (micro B) to wall wart adapter
• Data Connectors: 5-pin XLR

• Control Protocol: W-DMX, RDM
• Frequency (operating): # 2.4 GHz
• Universes per device: 1
• Number of DMX channels: 512
• DMX Latency: <5 msMax universe in coexistence: 16
• Error correction: yes
• DMX Fidelity: yes
• Adaptive Frequency Hopping: Yes
• W-DMX G3 &G4S compatibility: Yes
• Standard range: up to 650 ft (200 m)
• Internal antenna: Yes
• Sensitivity (0.1% PER): -97 dBm
• Modulation method: GFSK

• Input Voltage: 9 VDC 1000 mA, (external power supply: 100-230 V 50/60 Hz)

• WDMX Micro T-1 TRX G5
• Micro USB to wall wart adapter
• Velcro attachment strap
