Chauvet Q-Spot 150 LED DMX Moving Yoke

More Chauvet Professional products

Write a review Q&A SKU: Q-SPOT-LED-150 Solotech ID#: 54898
1 of 2
Unfortunately the Chauvet Q-Spot 150 LED DMX Moving Yoke is no longer available. This page is here for reference. Check out the great alternatives on this page, or contact us to speak with one of our sales advisors about similar products.

Need help? Contact our product specialists.

View full details
Unfortunately the Chauvet Q-Spot 150 LED DMX Moving Yoke is no longer available. This page is here for reference. Check out the great alternatives on this page, or contact us to speak with one of our sales advisors about similar products.

Need help? Contact our product specialists.

Description

CONTROL FEATURES


  • 9 or 11-channel DMX-512 LED moving yoke
  • Pan: 530º / Tilt: 270º
  • Color wheel: 8 colors + white / Rainbow color spin at variable speeds
  • Rotating gobo wheel with gobo shake: 7 interchangeable, slot-n-lock gobos + open / Gobo wheel spin at variable speeds
  • 3-facet prism
  • Variable electronic strobe
  • Variable electronic dimmer (0 – 100%)
  • Remote fixture reset
  • 255 user-programmable steps without DMX controller
  • Move-in-black for pan/tilt
  • Built-in automated programs
  • Built-in sound activated programs
ADDITIONAL FEATURES
  • High-powered, 20W (1000mA) LED
  • User-selectable pan/tilt ranges
  • Automatic pan/tilt correction
  • Reset to factory settings option
  • User-selectable basic or advanced operating modes
SPECIFICATIONS
  • Gobo size: 25.75mm outside, 18.2mm image, 1.2mm max thickness
  • Beam angle: 16
  • Lux: 4,180 @ 1m
  • Light source: 1 (white) LED 50,000hrs
  • Power and current: 120V, 60Hz: 50W, 0.4A operating, 0.1A inrush
  • Power and current: 230V. 50Hz: 50W, 0.2A operating, 0.1A inrush
  • AC power: Autoswitching 100V – 240V 50/60Hz
  • Weight: 13.5lbs (6.1kg)
  • Size: 9.5in x 9.47in x 14.3in / 242mm x 240mm x 364mm
POWER SPECS FOR BOX
  • AC power: Autoswitching 100V – 240V 50/60Hz
