Chauvet Maverick MK2 Profile LED Moving Head Light

Maverick MK2 Profile delivers ultimate artistic precision via its advanced 4-blade dual position rotating framing system, a stunningly bright 440 W LED engine, two 6-position rotating slot and lock gobo wheels, CMY + CTO color mixing, a 7-position + white color wheel, variable frost, 3-facet prism, and a 13° to 37° zoom range. Take control with DMX, sACN, Art-Net, or W-DMX, and test with RDM.

Features:

• Fully featured 440 W LED yoke profile fixture including CMY+CTO color mixing, a four blade framing shutter system with rotation, a color wheel, 3:1 zoom, and two rotating gobo wheels
• 16-bit dimming of master dimmer for smooth control of fades
• Variable CMY+CTO color mixing system to create a wide pallet of colors
• Two rotating, indexing and interchangeable slot and lock gobo wheels
• DMX , WDMX, sACN, and Art-Net for full flexibility of control options
• RDM control over DMX for fixture reporting
• 13° to 37° zoom angle for variable beam sizes
• Iris, 3-facet prism, and frost for beam control
• True 1 compatible power input
• Battery backup display with auto rotate depending on fixture orientation

Specifications:

• Light Source: 1 LEDs (CW) 469.1 W, (6.5), 6,016 K, 50,000 hours life expectancy
• Color Temperature (at full): 5883 K
• CRI: 90 li>
• Beam Angle: 12° to 35°
• Field Angle: 13° to 37°
• Zoom Angle: 13° to 37°
• Illuminance (13°): 14,981 lux @ 5 m
• Illuminance (36°): 2,098 lux @ 5 m
• Selectable PWM: 600Hz, 1,200Hz, 2,000Hz, 4,000Hz, 6,000Hz, 15,000Hz
• Pan and Tilt: 540°/270°
• Pan and Tilt Ranges: 540°, 360°, 180° pan/270°, 180°, 90° tilt
• Colors: 7 + white, split colors, continuous scroll at variable speeds
• Colors: CMY flags, CTO flag
• Gobos (1): 6 + open glass, rotating, interchangeable, indexing, slot-n-lock, continuous scroll at variable speeds
• Gobos (2): 6 + open glass, rotating, interchangeable, indexing, slot-n-lock, continuous scroll at variable speeds
• Gobo Size: Gobo Wheel 1 (rotating): 32 mm (outside), 28 mm (image), 1.1 mm (max. thickness)
• Gobo Size: Gobo Wheel 2 (rotating): 32 mm (outside), 26 mm (image), 1.1 mm (max. thickness)
• Framing Shutters: 4 blades, each with dual axis movement
• Framing Shutter rotation: 90°
• Dimmer: Electronic
• Shutter/Strobe: Electronic
• Zoom: Motorized
• Focus: Motorized
• Frost: Motorized
• Iris: Motorized
• Prism: 3 Facets, motorized, rotating
• Strobe Rate: 0 to 20 Hz
• Move-in-Black: Yes
• Dim Curves: 4
• Dimensions:15.5 x 10.9 x 26.4 in (394 x 279 x 671 mm)
• Weight: 69.8 lb (31.7 kg)
• Exterior Color: Black
• Housing Material: High-impact flame-retardant polymer
• Power Connection: Edison plug to Seetronic Powerkon IP65
• Power Input: Seetronic Powerkon IP65
• Data Connectors: 3- and 5-pin XLR, Amphenol XLR Net RJ45 Connectors in/out
• Cable Length (power): 5 ft (1.5 m)
• Control Protocol: Art-Net, DMX, W-DMX, sACN
• DMX Channels: 33 or 50
• Art-Net Channels: 33 or 50
• Modes/Personalities: 2 personalities (33, 50)
• Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
• Power and Current: 750 W, 6.32 A @ 120 V, 60 Hz
• Power and Current: 732 W, 3.5 A @ 208 V, 60 Hz
• Power and Current: 734 W, 3.1 A @ 230 V, 50 Hz
• Breaker Size: F12 A, 250 V
• CE, MET
• IP Rating: IP20, dry location
• Temperature (Ambient): -4 °F to 113 °F (-20 °C to 45 °C)
• Maverick MK2 Profile
• Seetronic Powerkon IP65 power cord
• Omega bracket with mounting hardware
• Maverick MK2 Profile
• Seetronic Powerkon IP65 power cord
• Omega bracket with mounting hardware
• Professional Clamps: CTC-50HC, CTC-50HCN
• Safety Cable: SC-07
• IP Rated Seetronic® Powerkon Extensions
• DMX cables
