Blackmagic DeckLink Duo 2 Video I/O Card

With four bi-directional SDI interfaces, the Blackmagic Design DeckLink Duo 2 is a versatile video I/O card for professional video workflows. Since each SDI interface can be configured to be either an input or an output, a computer with this card installed can be purposed as a media play-out system, a multi-screen digital signage server, a live keyer, a real-time multi-channel capture system, or a combination of the above to fit your specific workflow of the moment. A reference input is also available for syncing with other studio equipment.

Specifications:

  • Host Connection: PCIe x4 (PCIe 2.0)
  • Input:
    • Video Input Connectors: 4 x BNC (12G-SDI) Female
    • Input Video Format:
      • SDI (8/10/12-Bit 4:4:4/4:2:2 RGB, YUV):
        • 1080p: 23.98/24/25/29.97/30/50/59.94/60 fps
        • 1080PsF: 23.98/24/25/29.97/30 fps
        • 1080i: 50/59.94/60 fps
        • 720p: 50/59.94/60 fps
        • PAL: 50 fps
        • NTSC: 60 fps
    • Audio Input Connectors: None
    • Input Audio Format: Analog: 48 kHz / 24-Bit
    • Embedded Audio Input: SDI: 16-Channel
  • Standards:
    • Video Standard Compliance SMPTE 259M/292M/296M/372M/425M
    • ITU -R BT.601/BT.656
  • Connectivity: Other I/O 1 x BNC Blackburst, Reference, Tri-Level Sync Input
  • Hardware:
    • OS Compatibility:
      • Windows 8.1.10 or Later
      • macOS 10.14.15 or Later
      • Linux
    • Power Consumption: 10 W
  • Environmental:
    • Operating Temperature: 41 to 104°F / 5 to 40°C
    • Storage Temperature: -4 to 113°F / -20 to 45°C
    • Operating Humidity: 0 to 90%
  • General:
    • Certifications: C-Tick, CE, FCC, as per Manufacturer
    • Dimensions: 3.7" / 9.4 cm
    • Weight: 5.64 oz / 160 g
  • Packaging Info:
    • Package Weight: 0.54 lbs.
    • Box Dimensions (LxWxH): 5.65 x 5.55 x 1.2"
