Antari DFX-IPL510 DarkFX Strip 510 IP-65 Rated Outdoor UV Strip Fixture

The Antari DarkFX Strip 510IP UV Wash is an outdoor-rated professional high-output UV LED wash strip, well suited for UV reactive material, art, amusement park displays, and signage with bright and vivid colors. The 6 x 1.9W high-power UV LEDs offer a peak wavelength of 365nm and a radiant flux output of 4500mW at full intensity (and minimal visible light). The fixture offers a 25° beam angle and is flicker-free for TV and film production. Special optics prevent wear degradation from high UV exposure. The aluminum extruded housing features a built-in adjustable bracket. A 22 AWG power/data bare-wire-end pigtail cable is attached on the back and connects to the Antari DarkFX Drive 4 fixture driver (sold separately), which is required for power and DMX control.

Features:

• 6 x 1.9W High-Powered UV LEDs
• High Efficiency, IP65 Rated
• Outdoor Rated
• 25° Beam Angle
• Peak Wavelength: 365nm
• Radiant Flux Output: 4500 mW
• Flicker-Free Operation for TV and Film
• Adjustable Mounting Bracket
• Requires DarkFX Drive 4 for Power & DMX

Specifications:

• Light:
  • Fixture Type: Linear/Bar Light
  • Light Source: 6 x UV Fluorescent - 1.9 W
  • Expected Lamp Life: 20,000 Hours
  • Colors: Ultraviolet
  • UV Wavelength: 365 nm
  • Beam Angle: 25°
  • Shutter / Strobe: Electronic
  • Iris: No
  • Focus: Manual
  • Zoom Adjustment: No
  • Dimming: Electronic, 0 to 100%
• Performance:
  • Operating Modes: DMX, Static Color
  • Macros / Programs: No
  • Effects: Strobe (Variable Speed)
  • Strobe Rate: 0 to 20 Hz
  • Gobos: No
• Control:
  • Control Protocols: DMX512
  • Display / Controls: No
  • Remote Control: No
• Connectivity:
  • Inputs/Outputs: No
• Power:
  • AC Power Connector:
    • Input: Hard-Wired
    • Output: None
    • Plug Type: Unterminated/Bare Wire
  • DC Input Power: 20 to 24 VDC
  • Fuse: No
  • Power / Current Consumption: 14 W
  • Power Linking: No
• Environmental:
  • Environmental Protection:
    • Advertised as Weather Resistant
    • *Manufacturer Testing: IP65
• Physical:
  • Mounting: Mounting Bracket
  • Duty Cycle: No
  • Exterior Color: Black
  • Certifications: CE
  • Dimensions: 23.9 x 4 x 2.1" / 605.9 x 100.6 x 54.3 mm (with Bracket)
  • Weight: 2.4 lb / 1.1 kg
