ADJ American DJ PAR-Z150-RGBA 150 Watt RGBA Par Fixture with Wired Digital Communication Network
A modern twist on the classic halogen Par Can, the Par Z150 RGBA combines a potent 150-Watt C.O.B. LED light source with a traditional Par 64 enclosure. Offering a choice of beam angles and full color mixing, including white light with a color temperature of between 2300K and 9900K, it is ideal for washing both stages and dancefloors of all shapes and sizes.
Features:
- Linear white color temperature control (230K ~ 9900K)
- Color Temperature Presets (2300K ~ 9900K)
- 4-button DMX menu display on rear panel
- OLED display
- Adjustable latch to manually change beam angle
- Includes gel frame for diffusion filters (Diffusion filter sold separately)
- 64 Built-in Color Macros
- Strobe Rate: 0.6Hz to 7.5Hz
- Refresh Rate: 3KHz
- Electronic Dimming: 0 - 100%
- 6 Dim Modes
- 4 Dim Curves
- On-board, color balance feature for each color (RGBL)
- DMX-512
- 6 DMX control modes: (4/5/6/7/8/9/10/11 & 12 Ch. modes)
- RDM and RDM Net Compatible
- Primary/Secondary, stand-alone mode
- On-board manual control mode
- 150 Watt Quad RGBA C.O.B. LED (Chip On Board - Red, Green, Blue & Amber)
- Rated at 50,000 Hour Life expectancy
- 7, 11.5, 16, 20.5 or 25-degree Manual Zoom
- 3.3:1 Zoom Ration
Specifications:
- Optical:
- 150-Watt Quad RGBA C.O.B. LED (Chip On Board - Red, Green, Blue & Amber)
- Life expectancy: rated at 50,000 hrs.
- Manual Zoom: 7, 11.5, 16, 20.5 or 25-degrees
- Zoom Ration: 3.3:1
- Photometrics:
- 1360 Lux (Zoomed In to 7°)
- 487 Lux (Zoomed Out to 25°)
- CRI: >90
- Connection:
- DMX: 5-pin DMX In/Out
- With Wired Digital Communication Network
- Locking power In/Out connections
- Control:
- DMX-512
- 9 DMX control modes: (4/5/6/7/8/9/10/11 & 12 Ch. modes)
- RDM and RDM Net Compatible
- Primary/Secondary, stand-alone mode
- On-board manual control mode
- Electrical:
- Power Draw Total (All LED's @ Full On): 157W
- Power Consumption: 1.3A @ 120V/60Hz ; 0.7A @ 220V/50Hz
- Multi-voltage operation: AC 100-240V, 50/60Hz
- Daisy chain: 9 fixtures @ 120V; 17 fixtures @ 230V
- Fuse protected: 3A/250V
- Ambient Temperature Range (For Use):
- -4° ~ 113°F (-20°C ~ 45°C)
- Storage Temperature Range:
- -22° ~ 113°F (-30°C ~ 45°C)
- Dimensions / Weight:
- Dimensions (LxWxH): 19.25” x 10.94” x 10.68” / 489 x 277.7 x 272.1mm
- Weight: 7.94 lbs. / 3.6kg.
- IP Rating / Approvals:
- IP20
- CE & FCC
- ETL Approved
- Optical:
- 150-Watt Quad RGBA C.O.B. LED (Chip On Board - Red, Green, Blue & Amber)
- Life expectancy: rated at 50,000 hrs.
- Manual Zoom: 7, 11.5, 16, 20.5 or 25-degrees
- Zoom Ration: 3.3:1
- Photometrics:
- 1360 Lux (Zoomed In to 7°)
- 487 Lux (Zoomed Out to 25°)
- CRI: >90
- Connection:
- DMX: 5-pin DMX In/Out
- With Wired Digital Communication Network
- Locking power In/Out connections
- Control:
- DMX-512
- 9 DMX control modes: (4/5/6/7/8/9/10/11 & 12 Ch. modes)
- RDM and RDM Net Compatible
- Primary/Secondary, stand-alone mode
- On-board manual control mode
- Electrical:
- Power Draw Total (All LED's @ Full On): 157W
- Power Consumption: 1.3A @ 120V/60Hz ; 0.7A @ 220V/50Hz
- Multi-voltage operation: AC 100-240V, 50/60Hz
- Daisy chain: 9 fixtures @ 120V; 17 fixtures @ 230V
- Fuse protected: 3A/250V
- Ambient Temperature Range (For Use):
- -4° ~ 113°F (-20°C ~ 45°C)
- Storage Temperature Range:
- -22° ~ 113°F (-30°C ~ 45°C)
- Dimensions / Weight:
- Dimensions (LxWxH): 19.25” x 10.94” x 10.68” / 489 x 277.7 x 272.1mm
- Weight: 7.94 lbs. / 3.6kg.
- IP Rating / Approvals:
- IP20
- CE & FCC
- ETL Approved
