ADJ Focus Beam LED 80W Cool White Moving Head

The Focus Beam LED, a complimentary fixture to the other Focus Series moving heads, uses a powerful 80W LED engine to produce a powerful, 7400K, 5-degree beam from an advanced optical system. This fixture features motorized focus, two prism effects (rotatable 8-facet Circular and rotatable 6-facet Linear), and it has a built-in in frost filter for wash effects.

There are a variety of control options on the Focus Beam LED such as: DMX & RDM protocol, a variety of diming modes, fine pan and fine tilt options, and adjustable gamma and LED refresh rate settings. There is an on-board function display with 5 touch buttons making it easy to dial in custom settings.

The Focus Beam LED offers 13 dichroic colors plus white, and has 15 fixed GOBOs plus open and a GOBO shake effect.

There is a convenient USB port on the rear panel used to update firmware. The fixture has locking Seetronic In/Out connections to daisy chain power, and 3-pin DMX In/Out to link data. The fixture is compact and lightweight suitable for fixed installations or temporary, mobile event applications.

Features:

  • Pan & Pan Fine: 630 degrees
  • Tilt & Tilt Fine: 270 degrees
  • Multi-voltage operation: AC 100-240V, 50-60Hz (Auto Sensing)
  • Maximum Power Consumption: 136W @ 120V
  • Daisy chain: 15 units @ 120V; 30 units @ 230V
  • Dimensions (LxWxH): 17.59" x 10.96" x 7.54" / 447x279x192mm
  • Weight: 23 lbs. (10.2 kg)
