ADJ American DJ ENCORE-PROFILE-MINI-WW 35 Watt LED Profile Ellipsoidal with Wired Digital Network

Incredibly compact, yet impressively powerful, the ADJ Lighting Encore Profile Mini WW is a feature-packed ellipsoidal that is ideal for applications where space is at a premium. It features a 40W warm white (3000K) LED light engine, which offers an output of 900 Lumens and a phenomenally high CRI of >98. For maximum versatility, it can be used with a choice of two manual zoom lens options and is supplied with a holder for “E” size GOBOs. This small, but perfectly formed, luminaire is suitable for a wide range of applications, including small theatres, bar stages, museums, theme park attractions and window displays.

Features:

• Compact and versatile LED-powered ellipsoidal luminaire
• Utilizes a potent 35W warm white LED engine with a 50,000-hour average life expectancy and 3000K color temperature
• Precision-engineered optics deliver a crystal-clear 900 Lumen output with an even field and extremely high CRI of >98
• Compatible with two lens options (sold separately) for adapting the fixture depending on the beam angle required
• EP Mini Lens 1530 option offers a variable beam angle of 15° - 30°
• EP Mini Lens 2550 version provides wider options of 25° - 50°
• Can be used to project GOBO patterns and is supplied with a holder for standard “E” size GOBOs (GOBOs sold separately)
• Offers digital dimming with variable curves and a selection of dimming modes, variable speed strobing, and adjustable refresh rates for avoiding flicker in filming applications
• Convenient OLED menu display on the rear panel provides access to an intuitive menu interface for DMX addressing and configuration of the unit’s adjustable operating parameters
• Supplied with a variable angle hanging bracket that locks securely into place using a pair of large thumb tightening screws

Specifications:

• Source:
  • Engine: 35W Warm White LED
  • Average LED Life: 50,000 Hours
• Photometric Data:
  • CRI: > 98
  • Total Lumens: 900
  • Color Temperature: 3000K
• Effects:
  • Electronic Strobe and Dimming
  • Variable Dimming Curves and Dimming Modes
• Gobos:
  • Gobos Size: “E”
  • Metal Gobo Dimensions:
    • Outer Diameter: 45 mm
    • Image Diameter: 31 mm
  • Glass Gobo Dimensions:
    • Outer Diameter: 39.5 mm
    • Image Diameter: 31 mm
  • Gobo Holder: included (GOBOs are sold separately)
• Control:
  • DMX Channel Modes: 3 (1 / 3 / 4)
  • Adjustable Refresh Rates: 900-1500, 25,000 Hz
  • Control Panel: 4 Button
  • Menu Display: OLED
  • Wired Digital Communication Network
  • RDM (Remote Device Management)
• Connections:
  • Locking 5-pin XLR Connector In/Out
  • IP65 Locking Power In/Out
  • USB Service Port
• Electrical/Thermal:
  • Convection Cooled
  • AC 100-240V - 50/60Hz
  • Max Power Consumption:
    • 45.6W @ 120V
    • 45.7W @ 230V
  • Power Linking:
    • 25pcs Max @ 120V
    • 53pcs Max @ 230V
  • Minimum-Maximum Ambient Temperatures: 14° - 113°F (-10° - 45°C)
• Approvals/Ratings:
  • CE, cETLus (Pending)
  • IP Rating: IP20
• Physical:
  • Dimensions (LxWxH): 6.03” x 5.67” x 10.75” (153 x 144 x 273 mm)
  • Weight: 3.64 lbs (1.65 kg)
