Designed as part of the CCL family as a mobile specific small to medium format flyable cardioid subwoofer

• Components 1 x 15” + 1 x 10”
• Dispersion Cardioid
• SPLmax 134 dB
• Weight 44.5 kg / 98 lb

The CCL-SUB is a compact high performance cardioid subwoofer.

It houses two long excursion neodymium drivers in an integrated cardioid setup: a 15" driver in a bass-reflex design facing to the front and a 10" driver in a 2-chamber bandpass design radiating to the rear. The arrangement and tuning provide a cardioid dispersion pattern using a single amplifier channel. Its frequency response extends from 40 Hz to 150 Hz.
