Sony HDVF-C550W 5-Inch LCD Viewfinder HDC-HSC-HXC

The HDVF-C550W is a 5-inch HD LCD colour viewfinder for use with Sony high-definition cameras, such as the HDC, HSC, and HXC series.

Features:

• Wide viewing angle - IPS-LCD for ultra-wide viewing angle.
• Focus Assist function - The HDVF-C550W comes with a Focus Assist function for quick and accurate focusing.
• Preset adjustment settings - Brightness, contrast, peaking and Chroma levels can be pre-selected and assigned to a switch or menu item.

Specifications:

• General:
  • Power supply: 10.5 V to 17.0 V DC (supplied by the camera)
  • Power consumption: 8.2 W
  • Operating temperature: 0°C to 45°C (32°F to 113°F)
  • Dimensions (W x H x D) (excluding protrusions): 220 × 152.5 × 68 mm (8 3/4 × 6 1/8 × 2 3/4 in.) (Without hood)
  • Mass: 1.2 kg (2 lb 11 oz)
• Display Unit:
  • Size: 5.0-type Colour LCD
  • Effective screen size: 108.0 × 60.8 mm (H/V, 16:9 aspect ratio) (4 3/8 × 2 1/2 inches)
  • Effective pixels: 800 (horizontal) × 450 (vertical) × 3 (RGB)
• Performance:
  • Brightness: 300 cd/m2 (typical)
  • Resolution: 400 or more lines
  • Supported formats: 1080/23.98PsF,24PsF,25PsF,29.97PsF,30PsF,50i,59.94i, 60i
  • Colour Temperature: D65
• Connectors:
  • Camera connector: Round-type 20-pin
