Sony HDVF-200 2-Inch Viewfinder for 2/3-Inch ENG Camcorder

The Sony HDVF200 is an affordable alternative to the HDVF-20A HD viewfinder, designed specifically for Sony's line of 2/3" high definition ENG camcorders. The quality CRT housed in the viewfinder has 480 lines of resolution, making it ideal for monitoring footage and verifying focus. The unit comes with a removable eyepiece and easily attaches to most Sony 2/3" camcorders.

Features:

• Tally indicator (rear) - Lights up when the camera/camcorder receives a tally control signal. This indicator can be covered when not in use.
• Tally indicator (front) - Lights up when the camera/camcorder receives a tally control signal. Set the TALLY switch 9 to OFF when not in use. The brightness can also be adjusted with the TALLY switch 9.
• Peaking control - Turning this control clockwise adjusts the picture sharpness, and makes focusing easier. This control has no effect on the output signals of the camera/ camcorder.
• Contrast control - Adjusts the contrast of the screen. This control has no effect on the output signals of the camera/camcorder.
• Bright control - Adjusts the brightness of the screen. This control has no effect on the output signals of the camera/ camcorder.
• Tally switch - Controls the tally indicator 5 located on the front of the viewfinder. HIGH: The tally indicator brightness is set to high. OFF: The tally indicator is disabled. LOW: The tally indicator brightness is set to low.
• Zebra (zebra pattern) switch - Controls the zebra pattern display on the viewfinder screen as follows: ON: A zebra pattern appears and stays. OFF: The zebra pattern disappears. MOMENT: A zebra pattern appears and stays for about 5 seconds.
• Diopter adjustment ring - Allows for optimal focus adjustment.

Specifications:

• Display: 2" CRT
• Resolution: 480 TV Lines
• Packaging Info:
  • Package Weight: 2.58 lb
  • Box Dimensions (LxWxH): 13 x 10.5 x 7"
